- Vacuum Dryer
- 【Brief】：Vacuum Dryer for drying heat sensitive material, it’s widely used in pharmaceutical, chemical, food and electronic industries.
- 【Series】：Dryer
It’s suitable for drying heat sensitive material, it’s widely used in pharmaceutical, chemical, food and electronic industries.
Features:
1.Under the condition of vacuum,the boiling point of raw material will decrease and make the evaporation efficiency increase. Therefore for a certain amount of heat transfer, the conducting area of dryer can be saved.
2. The heat source for evaporation may be low pressure steam or surplus heat steam.
3. The heat loss is less.
4.Before drying,the treatment of disinfection may be carried out during the period of drying,there is no impurity material mixed. It is in conformity.
5. It belongs to static dryer. So the shape of raw material to be dried should not be destroyed.
Questions before quotation:
1. Material name
2. Material initial moisture and final moisture\
3. How many kg per batch or per day
4. Heating source is steam or hot water?
Techinical specification:
|
Model Name |
YZG-600 |
YZG-800 |
YZG-1000 |
YZG-1400A |
FZG-10 |
FZG-15 |
FZG-20 |
|
|
Inter size of drying chamber(mm) |
Φ600×976 |
Φ800×1247 |
Φ1000×1527 |
Φ1400×2054 |
1500×1060 ×1220 |
1500×1400 ×1220 |
1500×1800 ×1220 |
|
|
Outer size of drying chamber(mm) |
1135×810 ×1024 |
1700×1045 ×1335 |
1693×1190 ×150 |
2386×1675 ×1920 |
1513×1924 ×1720 |
1513×1924 ×2060 |
1513×1924 ×2500 |
|
|
Layers of baking support |
4 |
4 |
6 |
8 |
5 |
8 |
12 |
|
|
Interval of baking(mm) |
82 |
82 |
102 |
102 |
122 |
122 |
122 |
|
|
Size of baking tray(mm) |
310×600 ×45 |
520×410 ×45 |
520×410 ×45 |
460×640 ×45 |
460×640 ×45 |
460×640 ×45 |
460×640 ×45 |
|
|
Quantity of baking tray |
4 |
8 |
12 |
32 |
20 |
32 |
48 |
|
|
working pressure inside the pipe of baking support(Mpa) |
≤0.784 |
≤0.784 |
≤0.784 |
≤0.784 |
≤0.784 |
≤0.784 |
≤0.784 |
|
|
Operation temperature of baking support, oC |
35-150 |
35-150 |
35-150 |
35-150 |
35-150 |
35-150 |
35-150 |
|
|
Degree of vacuum inside the chamber when operation (Mpa) |
-0.09~0.096 |
|||||||
|
Under the condition of -0.1Mpa and 110oC,evaporation rate of water(kg/m2.hr ) |
7.2 |
7.2 |
7.2 |
7.2 |
7.2 |
7.2 |
7.2 |
|
|
When condenser is used,Model,and power of vacuum pump(kw) |
2X-15A 2KW |
2X-30A 3KW |
2X-30A 3KW |
2X-70A 5.5KW |
2X-70A 5.5KW |
2X-70A 5.5KW |
2X-90A 2KW |
|
|
When condenser is not used,Model,and power of vacuum pump(kw) |
SK-0.8 2.2KW |
SK-2.7 4KW |
SK-3 5.5KW |
SK-6 11KW |
SK-3 5.5KW |
SK-6 11KW |
SK-6 11KW |
|
|
Weight of drying chamber(kg ) |
250 |
600 |
800 |
1400 |
1400 |
2100 |
3200 |
|
